GY-F-250 Automatic Electromagnetic Iron - Remover
Application
- This machine is designed to remove ferrous contamination from liquid form of raw material in many industries, such as food, pharmaceutical, chemical, ceramic, electronics and etc. ( Operation temperature should be less than 80°C. )
Features
- Easy operation and cleaning, unique appearance
Cleaning
- In order to ensure maximum efficiency in removing iron particles, a cleaning schedule should be established on the basis of the amount of contamination removed.
- Magnetic bar set cleaning: Remove the magnetic bar set and turn it over (see diagram). Use a soft cloth and wipe from the top towards the bottom of de - Gaussing area to remove adhesive iron particles on the magnetic bar. Rinse the magnetic bar with clean water.
- In - feed tank cleaning: Remove the overflow plate. Rinse in - feed tank with clean water.
- (diagram) Magnetic bar set De-Gaussing area.
Note
- The magnetic bar has a strong magnetic field. Do not close to other magnetic objects during cleaning and operation to avoid any hazard situation.
- Do not scratch the surface of the magnetic bar with sharp objects under any circumstances.
- To avoid any hazard situation or weaken the magnetic strength, the magnetic bar should not be removed by unauthorized person.
Specification
● Magnetic field strength (GS): ≥9000
● Capacity (kg / hr): around 5,000 - 7,000 kg / hr (For clay material with a specific gravity of 1.6 - 1.8, flow rate of 100 ml: 40 - 80 secs)
● Net weight (kg): 30
