Polyethylene Film Fill Seal Packing Machine CY-305E

Overview
Yueh Chyun Machinery Co.,LTD is specialized in Packing Machine and Filling Machine .
Application
- The polyethylene film fill seal packing machine is designed for packing irregular shapes objects such as hardware parts - screws, bolts and automotive parts packages. Also the pharmaceuticals or frozen foods and other products suitable in PE bags are available.
Features
- Color touch screen - simple operating steps and user friendly.
- Servo motor for bag length control.
- Self-diagnostic functions - error and malfunction displays.
- Auto correcting print registration photocell.
- PID temperature control to provide quality sealing.
- PLC - programmable logical controller to allow additional facilities add-ons when needed.
- Production Records: batching setting, batching counting, total production counts.
- Integration with auto feeding system available.
- Multi Language Selections: English/Chinese.

Specification

MODEL	CY-305E
Packing Style	Pillow seal /
Bag Size	Standard - W:100-210L:100-280mm / Large - W:200-300L:200-400mm
Film Size	Standard - 230-450mm / Large - 430-630mm
Dosing Method	Multi-head computerized scale.
Capacity	15~40 bags/min.(subject to film quality, filling volume and product conditions.)
Voltage	220V/60Hz
Machine Weight	750kg
▲ Above specifications for standard machine only. ▲ Actual machine appearance may vary.
