Powder, Granule Auto Filling Packing Machine CY-I-II-III

Overview
Automatic filling packing machine for powders and granules is suitable for packing powders like instant coffee, hot coco, matcha green tea powder, energy drinks, juice powder, milk tea powder, spices, herbs etc. And the granules products such as sugar, salt, pepper, peanuts, green beans, loose tea leaves, seeds, cookies and other similar substances.
Application
- Powder and granules products.
Features
- Color Touch Screen: simple operating steps and user friendly.
- Self-diagnostic Functions: error and malfunction displays.
- Auto correction photocell - to provide accurate print registration to prevent defected packaging.
- Micro Computer Temperature Control - to ensure quality sealing.
- PLC: programmable logical controller to allow additional facilities add-ons when needed.
- Production Records: batching setting, batching counting, total production counts.
- Multi Language Selections: English/Chinese

Specification

MODEL	CY-I	CY-II	CY-III
Packing Style	Three Side Seal	Pillow Seal	Four Side Seal
Packing Size(mm)	W:25~90 x L:50~125	W:25~80 x L:50~125	W:25~90 x L:50~125
Film Width Range(mm)	50~180	50~180	50~180
Packing Speed	25~80 SACK/MIN	25~80 SACK/MIN	25~80 SACK/MIN
Voltage	220V, 50/60Hz	220V, 50/60Hz	220V, 50/60Hz
Machine Weight	380KGS	380KGS	380KGS
Machine Size LxWxH(mm)	1070 X 700X 1750mm	1070 X 700X 1750mm	1070 X 700X 1750mm
▲ Packing speed is subject to film quality, filling volume and product conditions. ▲ Above specifications for standard machine only. ▲ Actual machine appearance may vary.
