| Power |
110V, 50/60 Hz, Single Phase, 3.2 Amp (208V optional) |
| Air Pressure |
Minimum 87 psi |
| Air Consumption |
50 NLit/m (for optional reject and Lot/Date printer) |
| Speed |
Up to 120 Bottles per Minute (BPM) |
| Label Width / Height |
5/8" to 8-5/8" (15mm - 220mm) dependent on label head type |
| Label Length |
5/8" to 9-7/8" (15mm - 250mm) |
| Label Roll |
Max 13-3/4" (350mm) outside diameter with 3" (76mm) core |
| Bottle Height |
2" to 12-5/8" (50mm - 320mm) |
| Bottle Diameter |
1" to 4" (25mm - 102mm) dependent on conveyor width |
| Conveyor Width |
Standard 4" (also available in 6") |
| Conveyor Length |
Standard 79" (also available in 94" sanitary) |
| Conveyor Bed Height |
Standard 36" (+/- 2") |
| Machine Weight |
174 kg (383 LBS) |
