CHM-6030A Automatic Sleeve Type Sealer
Overview
The CHM-6030A auto sleeve sealer is applicable for sanitary facilities, boxed large items, spare parts, etc. It can work with or without a tray. It can be combined with a shrink packaging machine for the final wrapping process. Film used PE, PVC.
Features
- Automatic type for economic purpose, based on different requirements to convey the product automatic. Feeding, pushing-in and sealing automatically.
- Applicable for PE, POF shrink films
- Designed for the single product or groups of products such as: two rows, three rows or four rows with/without a tray
- PLC controlled to alter program easily.
- Easy operation and maintenance.
- Integrated applications sealing to save the packaging cost.
- The combination with a shrink tunnel for complete solution.
- Easy set up and replacement of film
- Feeding conveyor can be designed in the left side, right side or straight feeding type as per your demands.
Specification
Model |
CHM-6030A |
Power Supply |
1φ/3φ, 220V/240V |
Watts |
1.8 KW |
Sealing size / Tunnel size |
W600xH300mm |
Conveyor speed |
12M/min |
Conveyor size |
W300 mm |
Machine size |
L2100xW1500xH2000mm |
Air compressor |
6kg/cm² |
※CHA Pack reserves the right to modify specification for quality development.
OPTIONS
Mechanical aspect:
- .Customized specification availabe.
- .Feeding conveyor designed in the Left-to-right product flow, Right- to Left flow or Straight feeding type
Special needs:
- .#304 Stainless steel machine construction
- .Customized color
Video
Automatic Sleeve Type Sealer
-
