CHS-6801L Horizontal Carton Erecting Machine
Overview
Chuen An Machinery Industrial Co., Ltd is specialized in Box Erector and Carton Erecting Machine.
Features
- Horizontal type
- Suitable for handling by side loading
- For all general type of cardboard boxes
- To open the box then seal the bottom flaps
- Positive box opening with opposing vacuum system
- Capable of folding and sealing boxes with adhesive tape or hot melt glue
- PLC controlled to alter the program easily
- HMI control panel
- Locking casters as standard accessory
- Easy operation and maintenance.
- Malfunction alarm with 3 color light
- Detection for low-quantity of boxes
- Reverse feeding direction is available by request
- Safety interlocked guarding
- Easy operation and maintenance
- 100% Made in Taiwan Valued Quality
Specification
| Model |
CHS-6801L |
| Type |
Horizontal |
| Function |
Top & bottom belt driven |
| Power Supply |
3 phase, 220V/380V/415V |
| Tape Width |
2” or 3" |
| Feeding direction |
L type |
| Tape Sealing size |
L300-600mm, W220-500mm, H250-500mm |
| Tape overlap |
L60±5 (mm) standard |
| Working table height |
700mm |
| Capacity |
5-8 boxes/min. |
| Cardboard storage |
50-70 pcs ( depends on boxes thickness) |
| Machine dimension |
L3037xW2780xH2000mm |
| Air compressor |
6kg/cm² |
| Note |
Box dimension must match below format:
A=L+W; B=H+W/2 ;C=H+W
520mm300mm500mm |
※CHA Pack reserves the right to modify specification for quality development.
OPTIONS
Mechanical & Mechatronic aspect:
- ． Customized specifications
- ． Tape overlap 70±5mm
- ． Outside diameter of OPP tape 350mm
- ． CE Type
- ． Could combine with case sealers or strapping machine
- ． Detection for no tape and NG taping function
Special needs:
- ． #304 Stainless steel machine construction
- ． Customized color
Video
CHS-6801L Horizontal Carton Erecting Machine
-
