SY-M905HT Vertical Band Sealer

Overview
Showy Industrial CO., LTD is specialized in Vertical Band Sealer and Sealing Machine.
Application
- Applications for food,chemicals and hardware parts
- Packing materials: any heat sealable material.
- Suitable for product in large package or product that cannot be sealed by horizontal sealing machine.
Features
- From top of open mouth of pouch to sealing area max. Distance is 35mm.
- Built-in counting device.
- Built-in anomaly alarm device.
- Built-in speed display.
- Built-in 2 sets of temperature display, temperature control is more stable and accurate
Optional devices
- Stainless steel (SUS#304)
- Coder (solid ink or hot foil)

Specification

Model	SY-M905HT
Power	780W
Packing speed	0~10 m/minute (fixed speed)
Power supply	AC100V/110V, AC200V/220V/240V, single phase 50/60HZ
Conveying direction	From left to right
Conveyor width	200mm
Bag size	Within 600mm Long 400mm Wide
Temperature range	50℃~230℃
Heating power	350W×2pcs
Conveyor height adjustable range	500mm
Conveyor load weight	10 Kg
Sealing width	5mm (applicable to PE, PP) or10mm , either one
Packing material thickness	0.06-0.5mm (double-layer thickness)
Machine size	15306201750 (mm)
Packing size	16007201850 (mm)
Packing function	Sealing
N.W、G.W	140、220 (kg)
Remark	For the standard specifications described above, we reserve the right to change without prior notice.
