SY-M901T Horizontal Band Sealer

Overview
Showy Industrial CO., LTD is specialized in Horizontal Band Sealer and Sealing Machine.
Application
- Applications for food,chemicals and hardware parts
- Packing materials: any heat sealable material.
Features
- From top of open mouth of pouch to sealing area max. Distance is 35mm.
- Sealing head can be tilted 0~15° degree forward.
- Built-in counting device
- Built-in anomaly alarm device
- Built-in speed display
- Built-in 2 sets of temperature display, temperature control is more stable and accurate
Optional devices
- Stainless steel (SUS#304)
- Hot Foil Coder (Mark the date batch number)

Specification

Model	SY-M901T
Power	780W
Packing speed	0~10 m/minute (adjustable)
Power supply	AC100V/110V, AC200V/220V/240V, single phase 50/60HZ
Conveying direction	From left to right
Conveyor width	200mm
Bag size	Within 300mm Long 300mm Wide
Temperature range	50℃~230℃
Heating power	350W×2pcs (2 sets of temperature display)
Conveyor height adjustable range	90mm
Conveyor load weight	1 Kg
Sealing width	5mm (applicable to PE, PP) or10mm , either one
Packing material thickness	0.06-0.5mm (double-layer thickness)
Machine size	12005501100 (mm)
Packing size	12806801200 (mm)
Packing function	Sealing
N.W、G.W	120、180 (kg)
Remark	For the standard specifications described above, we reserve the right to change without prior notice.
